Alternator Regulators - BOSCH: Adjustment

NOTE: If regulator fails to keep voltage within specified limits, it must be replaced. No adjusting procedures are recommended.

Fig 1: Typical Bosch Transistorized Voltage Regulator Wiring Diagram
