Pressure Test Specifications
PUMP OUTPUT PRESSURE (PSI)
| Application | Idle Pressure | Relief Pressure | ||||
|---|---|---|---|---|---|---|
| American Motors | ||||||
| All 6 Cyl. | 80-125 | 1000-1100 | ||||
| All V8 | 80-125 | 1100-1200 | ||||
| Chrysler Corp. | ||||||
| 6 Cyl. With A/C | 1000-1100 | |||||
| V8 & 6 Cyl. Without A/C | 1200-1300 | |||||
| Ford Motor Co. | ||||||
| Ford Thompson (TRW) Pump | ||||||
| HBCW and V | 150 | 1050 | ||||
| HBC-U | 150 | 1200 | ||||
| HBC-T | 150 | 1300 | ||||
| Saginaw Pump (All) | 150 | 1350 | ||||
| General Motors | ||||||
| Cadillac (Exc. Seville) | 80-125 | 1425-1475 | ||||
| Corvette | 80-125 | 900-1000 | ||||
| All H Series(1) | 80-125 | 750-850 | ||||
| All Others | 80-125 | 1350-1450 | ||||
|
||||||
