Oxygen Sensor: Locations

RH Side Of Engine.:

In Exhaust Manifold

Applicable to: 1981 V8-255/4.2L & V8-302/5.0L Engines w/Microprocessor Control System (MCU)

RH Side Of Engine.:

In Exhaust Manifold

Applicable to: 1982 V8-255/4.2L Engine w/Microprocessor Control System (MCU)

LH Side Of Engine.:

In Exhaust Manifold

Applicable to: 1983 4-140/2.3L Engine

LH Side Of Engine.:

In Exhaust Manifold

Applicable to: 1984 V6-232/3.8L Engine

LH Side Of Engine.:

In Exhaust Manifold

Applicable to: 1985 4-140/2.3L Engine

LH Side Of Engine.:

In Exhaust Manifold

Applicable to: 1985 V6-232/3.8L Engine
