Removal & Installation
Drain radiator and remove negative battery cable. Disconnect throttle cable. Remove air duct from throttle body. Disconnect Throttle Position Switch (TPS) connector. Mark all coolant and vacuum hoses for reassembly reference and remove from throttle body. See Figure . Remove intake plenum bolts and remove intake plenum. To install, reverse removal procedure. Use new intake plenum-to-intake manifold gasket. See TORQUE SPECIFICATIONS .
