Keyless Entry Module
>>
Locations
>>
Coupe
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Coupe
Full-Body View (Coupe):
The Remote/Keyless Entry Module is located at the LH rear of trunk, behind side trim.
