CD4E - PCM REPROGRAMMING WHEN REPLACING TRANSAXLE

TECHNICAL SERVICE BULLETIN

Reference Number(s): 98-24-2, Date of Issue: December 7, 1998

TRANSAXLE - CD4E - POWERTRAIN CONTROL MODULE (PCM) REPROGRAMMING INFORMATION WHEN REPLACING TRANSAXLE

APPLICATION

Model(s): Ford: 1998-99 Contour

Lincoln-Mercury: 1998-99 Mystique

1999 Cougar

Bulletin No.: 98-24-2

Date: December 7, 1998

Calibration: 8-04A-R10, 8-04A-R12, 8-04P-R10, 8-04P-R12, 8-12B-R10, 8-12T-R10, 9EQA-AAF, 9EQA-BAF, 9LCA-AAE, 9LCA-BAE, 9LCA-ABE, 9LCA-BBE

WARNING: This modification is authorized only for the listed engine(s). Performing this modification on other engine calibrations is unauthorized and could create liability under applicable federal or local laws.

ISSUE

Some 1998/99 Contour/Mystique and 1999 Cougar vehicles may require Powertrain Control Module (PCM) reprogramming when installing a replacement CD4E transaxle.

ACTION

Refer to the following text and RECALIBRATION CROSS REFERENCE CHART to determine if PCM reprogramming is required.

Check build date on vehicle:

If build date is after 5/31/1998 for Contour/Mystique or after 6/11/1998 for Cougar, no PCM reprogramming is required. The PCM calibration has been updated during the manufacturing process.
If the build date is through 5/31/1998 for Contour/Mystique or through 6/11/1998 for Cougar, PCM reprogramming is required.

NOTE: If TSB 98-13-11 , which incorporates PCM reprogramming and a revised transaxle servo rod and spring, has been performed, PCM reprogramming is not necessary. Be sure to check the vehicle for an updated Authorized Modifications Decal (FPS-8262) which states TSB 98-13-11 has been performed before reprogramming PCM.

NOTE: If PCM reprogramming was necessary, install an Authorized Modifications Decal.

Obtain an Authorized Modifications Decal (FPS 8262 - obtainable through DOES II, 25/pkg) and list the date, dealer number, and summary of modifications performed. See Fig 1 . Select a prominent place adjacent to the Vehicle Emission Control Information Decal suitable for installing the Authorized Modifications Decal. Clean the area, install the decal, and cover it with a clear plastic decal shield.

WARRANTY INFORMATION

WARRANTY STATUS: Information Only.

OASIS CODES: 501000, 502000, 504000

Fig 1: Authorized Modifications Decal
