Vehicle Emission Control Information Label

The Vehicle Emission Control Information (VECI) label contains emission control information specific to the vehicle and engine. Specifications on this label are critical to servicing emissions systems on the vehicle. In addition to tune-up specifications and procedures, VECI also includes a schematic of engine vacuum system. VECI is attached to under side of hood or on radiator support sight shield. See Fig 1 .

Fig 1: Vehicle Emission Control Information Label

Courtesy of FORD MOTOR CO.

NOTE: Vacuum diagrams for applications not shown are not available from manufacturer. See underhood label.

VACUUM DIAGRAM APPLICATIONS

Application/Calibration No. ⁽¹⁾

See

Continental

4.6L

9-VWA-BCD (YPT3)

Fig 2

Contour

2.0L 16-Valve - Except Flex-Fuel

9-EQA-ADE (VZO5), 9-EQA-BDE (XTJ5), 9-EQM-ADD (RXB4), 9-EQM-BDD (SYC4)

Fig 3

9-EQA-ASG (KLP0), 9-EQA-BSG (MML0), 9-EQA-BSH (MML1), 9-EQM-AAE (EXY4), 9-EQM-BAE (FUA4), 9-EQM-BAF (FKA5)

Fig 4

2.0L Flex-Fuel

9-EQA-BRC

Fig 4

2.5L - Except High Output

9-LCA-ASF (AZB0), 9-LCA-BSG (BLC1), 9-LCM-AAD (KKT3), 9-LCM-AAE (KKT4), 9-LCM-AGC (SPG2), 9-L6M-AGB (SFG1), 9-LCM-BAD (LTZ3), 9-LCM-BAE (LTZ4)

Fig 5

9-LCA-ACD (LXP3), 9-LCA-BCD (MZZ3), 9-LCM-ACD (JTA3), 9-LCM-BCD (DAR3)

Fig 6

2.5L High Output

9-1CM-AHC (MNQ2)

Fig 7

Cougar

2.0L 16-Valve

9-EQA-ACE (ATL4), 9-EQA-ATG (LKH0), 9-EQA-BCE (BBG4), 9-EQA-BTG (ERT0), 9-EQM-ACE (CNV4), 9-EQM-BCE (DLE4)

Fig 4

2.5L

9-LCA-ABE (VLM4), 9-LCA-ASF (AZB0), 9-LCA-ATF (FPT0), 9-LCA-BBE (XPP4), 9-LCA-BSG (BLC1), 9-LCA-BTG (YEB0), 9-LCM-AAE (KKT4), 9-LCM-ABD (SSD3), 9-LCM-ABE (SSD4), 9-LCM-BAD (LTZ3), 9-LCM-BAE (LTZ4), 9-LCM-BBD (TRW3), 9-LCM-BBE (TRW4)

Fig 5

9-LCA-ADD (GGR3), 9-LCM-ADD (EDL3)

Fig 6

Crown Victoria

4.6L - Except Natural Gas

9-VNA-AAB (ARA1), 9-VNA-AAD (ARA3), 9-VNA-AAE (ARA4), 9-VNA-AKB (FJB), 9-VNA-AKC (FJB2), 9-VNA-ALC (JCA2), 9-VNA-BKB (GCA1)

Fig 8

4.6L Natural Gas

8-18L-R06 (TQW2)

Fig 9

Escort

Except Escort ZX2

2.0L

8-07C-R11 (CGG4), 8-08B-R11 (EZA4), 8-07C-R11 (GAO4), 8-07P-R11 (HMC4), 9-EQA-AGA (GLE0), 9-EQA-AHA (ZKG0), 9-EQA-BGA (LRS0), 9-EQM-GA (CGW0), 9-EQM-BGA (YCC0), 9-EQM-BGB (YCC1)

Fig 10

Escort ZX2

2.0L 16-Valve

8-03E-R13 (MTA8), 8-03R-R13 (PPD8), 8-04E-R13 (KVT8), 8-04R-R13 (LLW8), 9-EQA-ABD (AYB3), 9-EQA-AKA (ZZM0), 9-EQA-BBD (BAX3), 9-EQA-BKA (PLR0), 9-EQM-ABC (CIL2), 9-EQM-AKA (TS20), 9-EQM-AMA (JHJ0), 9-EQM-BKA (HSB0), 9-EQM-BMA (NGP0)

Fig 4

Grand Marquis

4.6L - Except Natural Gas

9-VNA-AKB (FJB), 9-VNA-AKC (FJB2), 9-VNA-ALC (JCA2), 9-VNA-BKB (GCA1)

Fig 8

Mustang

3.8L - Except California LEV ⁽²⁾

9-LMA-ABB (BEH1) - Code FYY, 9-LMM-ABC (FAZ2) - Code FYY

Fig 11

9-LMA-ABB (BEH1) - Code FZF, 9-LMM-ABB (FAZ1), 9-LMM-ABC (FAZ2) - Code FZF

Fig 12

3.8L California LEV ⁽²⁾

9-LMA-BAB (CUR1), 9-LMM-BBB (HGH1), 9-LMM-BBC (HGH2)

Fig 13

4.6L - Except Cobra

9-VXA-AAB (BTB1), 9-VXA-AAC (BTB2), 9-VXA-ABB (CHH1), 9-VXA-ABC (CHH2), 9-VXA-BAB (DER1), 9-VXA-BAC (DER2), 9-VXA-BBC (EPM2), 9-VXM-AAB (FTL1), 9-VXM-AAC (FTL2), 9-VXM-ABB (GTG1), 9-VXM-ABC (GTG2), 9-VXM-BAC (HJX2), 9-VXM-BAD (HJX3), 9-VXM-BBD (JKU3)

Fig 14

4.6L Cobra

9-VMM-ABB (ZMR1), 9-VMM-ABC (ZMR2)

Fig 14

Mystique

2.0L 16-Valve - Except Flex-Fuel

9-EQA-ADE (VZO5), 9-EQA-BDE (XTJ5), 9-EQM-ADD (RXB4), 9-EQM-BDD (SYC4),

Fig 3

9-EQA-ASG (KLP0), 9-EQA-ASH (KLP1), 9-EQA-BSG (MML0), 9-EQA-BSH (MML1), 9-EQM-AAE (EXY4), 9-EQM-BAE (FUA4), 9-EQM-BAF (FKA5)

Fig 4

2.0L Flex-Fuel

9-EQA-ARC

Fig 4

2.5L

9-LCA-ASF (AZB0), 9-LCA-BSG (BLC1), 9-LCM-AAD (KKT3), 9-LCM-AAE (KKT4), 9-LCM-BAD (LTZ3), 9-LCM-BAE (LTZ4)

Fig 5

9-LCA-ACD (LXP3), 9-LCA-BCD (MZZ3), 9-LCM-ACD (JTA3), 9-LCM-BCD (DAR3)

Fig 6

Sable

3.0L OHV

9-LAA-AAB (RAL1), 9-LAA-AAC (RAL2), 9-LAA-ABB (SYA1), 9-LAA-ABC (SYA2), 9-LAA-ABD (SYA3), 9-LAA-BNA (GAF0), 9-LAA-BSA (MYD0), 9-1AA-AAD (RAL3)

Fig 15

3.0L DOHC

Except LEV ⁽²⁾

9-LDA-ABB (VIL1), 9-LDA-BAB (WEH1), 9-LDA-BAC (TQB0), 9-LDA-BAD (TQB1), 9-LDA-BDB (RRU0), 9-LDA-BDC (RRU1), 9-LDA-ABC (EBV0), 9-LDA-ABD (EBV1), 9-LDA-ADB (JMB0), 9-LDA-ADC (JMB1)

Fig 16

LEV ⁽²⁾

8-14A-R10 (YPZ2)

Fig 15

Taurus

3.0L OHV

Except Flex-Fuel

9-LAA-AAB (RAL1), 9-LAA-AAC (RAL2), 9-LAA-ABB (SYA1), 9-LAA-ABC (SYA2), 9-LAA-ABD (SYA3), 9-LAA-BNA (GAF0), 9-LAA-BSA (MYD0), 9-1AA-AAD (RAL3)

Fig 15

Flex-Fuel

9-LAA-ACB (MAB1)

Fig 17

3.0L DOHC

Except LEV ⁽²⁾

9-LDA-ABB (VIL1), 9-LDA-BAB (WEH1), 9-LDA-BAC (TQB0), 9-LDA-BAD (TQB1), 9-LDA-BDB (RRU0), 9-LDA-BDC (RRU1), 9-LDA-ABC (EBV0), 9-LDA-ABD (EBV1), 9-LDA-ADB (JMB0), 9-LDA-ADC (JMB1)

Fig 16

LEV ⁽²⁾

8-14A-R10 (YPZ2)

Fig 15

3.4L SHO

8-10D-R10 (EFL3), 8-10D-R11 (AZD0), 8-10M-R10 (GQD3), 8-10M-R11 (LBE0)

Fig 18

Town Car

4.6L

9-VNA-AMB (GDB1), 9-VNA-AMB (GDB2), 9-VNA-BHB (BBY1), 9-VNA-BHC (BBY2), 9-VNA-BMB (JFB1), 9-VNA-BSB (VDA1)

Fig 8

Tracer

2.0L

8-07C-R11 (CGG4), 8-07C-R11 (GAO4), 8-07P-R11 (HMC4), 8-08B-R11 (EZA4), 9-EQA-AGA (GLE0), 9-EQA-AHA (ZKG0), 9-EQA-BGA (LRS0), 9-EQM-GA (CGW0), 9-EQM-BGA (YCC0), 9-EQM-BGB (YCC1)

Fig 10
