Oil Pressure Sender: Material

WARNING: This page is about a different car, the 2005 Mercury Montego, 2005 Ford Freestyle, and 2005 Ford Five Hundred. However, it is still accessible from the selected car via links, so may be relevant.
ITEM SPECIFICATION

Item Specification
Thread Sealant with PTFE TA-24 WSK-M2G350-A2
Fig 1: Exploded View Of Oil Pressure Sender And Components
G03990189Courtesy of FORD MOTOR CO.
