Wheel Speed Sensor - Rear: Notes

WARNING: This page is about a different car, the 2008 Ford RV Cutaway, 2008 Ford Econoline, 2008 Ford E450 Super Duty, and 2008 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Exploded View Of Rear Wheel Speed Sensor - Traction Control and Stability Assist With Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	W500223	Rear wheel speed sensor bolt
2	-	Spacer
3	2C216 LH/ 2C190 RH	Rear wheel speed sensor
