Ambient Lighting Module: Notes

WARNING: This page is about a different car, the 2010 Mercury Mariner and 2010 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Ambient Lighting Module Components
G06390921Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION CHART

Item Part Number Description
1 7E391 Selector lever trim ring
2 - Floor console storage bin
3 045A76 Floor console finish panel
4 W701679 Ambient lighting module screws (2 required)
5 - Ambient lighting module electrical connector (part of 14D375)
6 13C788 Ambient lighting module
