Speed Control Switch

WARNING: This page is about a different car, the 2004 Lincoln LS. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the air bag. For additional information, refer to AIR BAG RESTRAINT SYSTEMS .
  2. Remove the parts in the order indicated in the following illustration and table.
    Fig 1: Removing Air Bag
    G03202151Courtesy of FORD MOTOR CO.
  3. To install, reverse the removal procedure.
