Electronic Brake Distribution
Electronic brake force distribution (EBD) takes the place of pressure conscious regulators (PCRVs) used in conventional braking systems and features in all ABS/TCS systems.
The EBD function is an additional programme (software) to the conventional ABS programme that allows greater utilization of the rear brakes up to the point of ABS intervention.
It can come into operation during regular braking, dependent on the loading of the vehicle and the surface friction.
In contrast to the PCRV, during EBD control the brake force is determined not by the brake pressure or vehicle speed but by the wheel slip.
