Footwell Duct - Rear: Notes

WARNING: This page is about a different car, the 2008 Mercury Mariner and 2008 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Footwell Duct Components - Rear

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	14401	Wire harness
2	-	LH floor duct (part of 18C464)
3	W701259	RH floor duct pin-type retainer
4	-	RH floor duct (part of 18C464)
