Power Steering System Filling
- Fill the power steering reservoir to the appropriate level.
- Remove the coil on plug (COP) Fuse 12 in the underhood auxiliary junction box (AJB) to disable the engine from starting.
- Raise the front wheels off the floor. For additional information, refer to JACKING & LIFTING .
- Turn the steering wheel from stop-to-stop while cranking the engine.
- Lower the vehicle.
- Fill the power steering fluid reservoir to the appropriate level.
- Install the COP fuse.
- Clear the diagnostic trouble codes (DTCs). For additional information, refer to SELF-DIAGNOSTICS - CNG, FLEX-FUEL & GASOLINE
.
- Run the vehicle and check the system for leaks.
WARNING:
Do not mix fluid types. Any mixture of an unapproved fluid could lead to seal deterioration and leaks. A leak could ultimately cause loss of fluid, which could result in a loss of power steering assist.
CAUTION:
Do not operate the starter motor for more than 10 seconds at a time. Damage to the starter motor could result.
CAUTION:
Do not overfill the power steering fluid reservoir.
NOTE:
If the power steering is noisy and accompanied by evidence of aerated fluid, it will be necessary to purge the power steering system. For additional information, refer to POWER STEERING SYSTEM PURGING .
