WARNING: This page is about a different car, the 2003 Mercury Mountaineer and 2003 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Diagnostic Trouble Code Chart (1 Of 14)
Courtesy of FORD MOTOR CO.
Fig 2: Identifying Diagnostic Trouble Code Chart (2 Of 14)
Courtesy of FORD MOTOR CO.
Fig 3: Identifying Diagnostic Trouble Code Chart (3 Of 14)
Courtesy of FORD MOTOR CO.
Fig 4: Identifying Diagnostic Trouble Code Chart (4 Of 14)
Courtesy of FORD MOTOR CO.
Fig 5: Identifying Diagnostic Trouble Code Chart (5 Of 14)
Courtesy of FORD MOTOR CO.
Fig 6: Identifying Diagnostic Trouble Code Chart (6 Of 14)
Courtesy of FORD MOTOR CO.
Fig 7: Identifying Diagnostic Trouble Code Chart (7 Of 14)
Courtesy of FORD MOTOR CO.
Fig 8: Identifying Diagnostic Trouble Code Chart (8 Of 14)
Courtesy of FORD MOTOR CO.
Fig 9: Identifying Diagnostic Trouble Code Chart (9 Of 14)
Courtesy of FORD MOTOR CO.
Fig 10: Identifying Diagnostic Trouble Code Chart (10 Of 14)
Courtesy of FORD MOTOR CO.
Fig 11: Identifying Diagnostic Trouble Code Chart (11 Of 14)
Courtesy of FORD MOTOR CO.
Fig 12: Identifying Diagnostic Trouble Code Chart (12 Of 14)
Courtesy of FORD MOTOR CO.
Fig 13: Identifying Diagnostic Trouble Code Chart (13 Of 14)
Courtesy of FORD MOTOR CO.
Fig 14: Identifying Diagnostic Trouble Code Chart (14 Of 14)
