Test L

PINPOINT TEST L: DTC B1318 - LOW IGNITION VOLTAGE DURING SPEED CONTROL OPERATION

Test L1:

Normal Operation
The speed control actuator is powered through circuit 601 (LB/PK) and is grounded through circuit 1205 (BK).

Possible Causes
- circuit 1205 (BK) open
