Air Flow Meter/Sensor: Service and Repair

MASS AIR FLOW (MAF) SENSOR







Removal and Installation
1. Disconnect the battery ground cable.
2. Disconnect the mass air flow (MAF) sensor electrical connector.
3. Remove the 4 nuts and the MAF sensor.
- To install, tighten to 10 Nm (89 lb-in).

4. To install, reverse the removal procedure.
