Connecting Rod, Engine

Connecting Rod Bolts






Stage 1: Tighten to 43 Nm (32 ft. lbs.).
Stage 2: Tighten an additional 105 degrees.

Connecting Rod
Big end journal inside diameter with assembled liners 53.049 - 53.027 mm
Rod bearing-to-journal clearance 0.064 - 0.026 mm
Pin bore diameter (rod) 22.024 - 22.012 mm
