Removal and Installation

  1. Disconnect the battery. For additional information, refer to BATTERY, MOUNTING AND CABLES .
  2. Remove the 2 bolts and the steering wheel rotation sensor.
    • Disconnect the electrical connector.
      Fig 1: Disconnecting Electrical Connector
      G03928873Courtesy of FORD MOTOR CO.
  3. To install, reverse the removal procedure.
