Safety Belt Buckle - Third Row: Notes

Fig 1: Exploded View Of Third Row Safety Belt Buckle With Torque Specifications
GF0032865Courtesy of FORD MOTOR CO.
Item Part Number Description
1 01318 Safety belt buckle bolt, RH
2 600A38-B Safety belt buckle assembly, RH
3 01318 Safety belt buckle bolt, LH
4 600A39 Safety belt buckle assembly, LH
