Safety Belt Retractor - Third Row: Notes

NOTE: RH side shown, LH side similar.
NOTE: Vehicle may be equipped with a power liftgate motor assembly.
Fig 1: Exploded View Of Third Row Safety Belt Retractor With Torque Specifications
GF0032870Courtesy of FORD MOTOR CO.
Item Part Number Description
1 - Safety belt anchor bolt
2 601B32 Safety belt guide D-ring cover
3 - Safety belt guide D-ring bolt
4 - Safety belt and retractor assembly bolt
5 611B68 Safety belt and retractor assembly
