Steering Column Shroud: Notes

Fig 1: Index-Marking Steering Column Shaft Position To Steering Gear
G00468746Courtesy of FORD MOTOR CO.
Item Part Number Description
1 3530 Upper steering column shroud
2 W707658 Lower steering column shroud screws (3 required)
3 3K512 Lower steering column shroud
