Power Window Switch: Service and Repair

Window Control Switch

Removal and Installation

NOTE: LF shown, all others similar.

1. Remove the door trim panel. For additional information, refer to Interior Trim and Ornamentation Service and Repair.

2. NOTE: There are 2 tabs on the opposite side not shown in the illustration.

Unlock the 4 tabs and remove the window control switch from the door trim panel.





3. To install, reverse removal procedure.
