Steering Wheel Rotation Sensor: Notes

Fig 1: Identifying Steering Wheel Rotation Sensor Components
G07806233Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION

Item Part Number Description
1 - Steering wheel rotation sensor electrical connector (part of 14489)
2 W506942 Steering wheel rotation sensor bolts (2 required)
3 3F818 Steering wheel rotation sensor
