Module-Body Control C2 (Standard) Connector End View (D2762B)

Harness-Family: Body

Color: BLUE

Gender: FEMALE

Part Number: 4540315_4545100

Part Description: Not Available

Connector No: D2762B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Body Control C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Body Control C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A906

8.0

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
