Code 28 - Main O2 Sensor CKT (Federal - Rear O2 Sensor)

NOTE: After repairs are completed, perform TROUBLE CODE DETECTION DRIVING PATTERN TEST.

Fig 1: Code 28 Rear Oxygen Sensor Flow Chart (GS300 - Federal) Main O2 Sensor Circuit (Rear O2 Sensor)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
