Removal and Installation

REMOVAL
1. REMOVE RADIO AND A/C CONTROL ASSEMBLY




2. REMOVE A/C CONTROL ASSEMBLY
Remove the 4 screws and the A/C control assembly.

INSTALLATION
Installation is in the reverse order of removal
