Integrated Power Module: Removal

WARNING: This page is about a different car, the 2004 Chrysler Pacifica. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect and isolate the battery negative cable.
Remove the hood cable retaining clip near the Integrated Power Module (IPM).
Using a flat bladed tool, depress the four locking tabs on the side of the IPM (Fig 1 )

Fig 1: Identifying Integrated Power Module
Courtesy of DAIMLERCHRYSLER CORP.
Lift the IPM from the bracket.
Disconnect the electrical harness connectors from the IPM.
Disconnect the battery connection to the IPM by removing the nut attaching the connection to the bolt.
