Torque Specifications
WARNING: This page is about a different car, the 2004 Toyota 4Runner and 2003 Toyota 4Runner. However, it is still accessible from the selected car via links, so may be relevant.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||||
|---|---|---|---|---|---|
| Engine Under Cover Bolts | 21 (29) | ||||
| Intake Manifold Assembly | |||||
| Bolts | 13 (18) | ||||
| Nuts | 13 (18) | ||||
| Manifold Stay Bolts | 30 (40) | ||||
| Starter Mounting Bolts | |||||
| V6 | 27 (37) | ||||
| V8 | 29(39) | ||||
| Water Bypass | |||||
| Joint Nuts | 13 (18) | ||||
| Pipe Bolt | 13 (18) | ||||
| Yoke Bolts | 27 (36) | ||||
| INCH Lbs. (N.m) | |||||
| End Cover Bolts | |||||
| 1.4 Kw | 13 (1.5) | ||||
| 1.6 Kw | 53 (6) | ||||
| 2.0 Kw | 34 (3.8) | ||||
| Starter Through Bolts | |||||
| 1.4 Kw | 52 (5.9) | ||||
| 1.6 Kw | 53 (6) | ||||
| 2 Kw | 82 (9.3) | ||||
| Magnetic Switch | |||||
| Terminal No. 30 Nut | 87 (9.8) | ||||
| Terminal "C" Nut | |||||
| 1.4 Kw | 52 (5.9) | ||||
| 1.6 Kw | 88 (10) | ||||
| 2 Kw | 52 (5.9) | ||||
| Screws | |||||
| 1.4 Kw | 52 (5.9) | ||||
| 1.6 Kw | 66 (7.5) | ||||
| 2 Kw | 82 (9.3) | ||||
| Wire Harness Nut | 115 (13) | ||||
|
|||||
