Power Door Lock Control System: Location

WARNING: This page is about a different car, the 2002 Toyota Prius. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Locating Power Door Lock Control System Components
G01895530Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
