(3) - The Down Function Does Not Work Though Some Other Objects Are Caught In The Power Window Glass

WARNING: This page is about a different car, the 2002 Toyota Prius. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Diagnostic Procedure For Down Function Problems
G01895512Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
