Accelerator Pedal Rod ASSY: Replacement

WARNING: This page is about a different car, the 2005 Toyota Sienna. However, it is still accessible from the selected car via links, so may be relevant.

REMOVE ACCELERATOR PEDAL ROD ASSY
1. Disconnect the accelerator position sensor connector.
2. Remove the 2 bolts and the accelerator pedal rod.
Fig 1: Removing Accelerator Pedal Rod Assy
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL ACCELERATOR PEDAL ROD ASSY
Torque: 7.5 N.m (76 kgf.cm, 66 in.lbf)
