Ignition Or Starter Switch ASSY: Replacement

REMOVE INSTRUMENT PANEL SUB-ASSY LOWER
(See INSTRUMENT PANEL SAFETY PAD SUB-ASSY (FROM JULY, 2003) )
REMOVE IGNITION OR STARTER SWITCH ASSY
1. Disconnect the ignition switch connector and unlock warning switch connector.
2. Remove the clamp.
3. Remove the 2 screws and ignition switch.
Fig 1: Removing Screws And Ignition Switch
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
