Millimeter Wave Radar Sensor ASSY: Replacement

  1. SEPARATE BATTERY NEGATIVE TERMINAL
  2. REMOVE MILLIMETER WAVE RADAR SENSOR ASSY
    1. Disconnect the connector.
    2. Remove the 3 bolts and millimeter wave radar sensor.
    Fig 1: Removing Millimeter Wave Radar Sensor Assy
    G02997751Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  3. INSTALL MILLIMETER WAVE RADAR SENSOR ASSY
    1. Install the millimeter wave radar sensor with the 3 bolts.
      1. Torque: 5.5 N.m (56 kgf.cm, 49 in.lbf)
    2. Connect the connector.
  4. ADJUST MILLIMETER WAVE RADAR SENSOR ASSY (See  ADJUSTMENT   )
