Rear Quarter Window Glass: Components

Fig 1: Identifying Rear Quarter Window Glass Replacement Components (1 Of 2)
G05864089Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Rear Quarter Window Glass Replacement Components With Torque Specifications (2 Of 2)
G05281114Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
