Accelerator Pedal Rod: Removal: Removal

  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
    WARNING:

    Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.

  2. REMOVE ACCELERATOR PEDAL ROD
      Fig 1: Locating Accelerator Pedal Rod With Bolts
      GTY129691Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    1. Disconnect the sensor connector.
    2. Remove the 2 bolts and pedal rod.
      NOTE:
      • Do not drop or strike the accelerator pedal.
      • Do not disassemble the accelerator pedal.
