Intake Manifold

Install 2 new gaskets and the intake manifold with the 4 bolts and 4 nuts
Torque 21 Nm (214 kgf-cm, 15 ft-lbf)

Intake Surge Tank

Install the intake air surge tank assembly with the 2 nuts.

Torque 16 Nm (163 kgf-cm, 12 ft-lbf)

Install the 6 bolts

Torque 18 Nm (184 kgf-cm, 13 ft-lbf)

Install the surge tank stay with the bolt

Torque 21 Nm (214 kgf-cm, 15 ft-lbf)
