Rear Speed Sensor: Removal: Removal

HINT:

• Use the same procedure for the RH side and LH side.
• The procedure listed below is for the LH side.
• If the sensor rotor needs to be replaced, replace it together with the rear axle hub and bearing assembly.

1. REMOVE REAR WHEEL
2. REMOVE REAR SPEED SENSOR WIRE
   1. Using a screwdriver, disconnect the rear speed sensor wire.
      Fig 1: Disconnecting Rear Speed Sensor Wire

      Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
3. REMOVE REAR SPEED SENSOR
   1. Remove the bolt and rear speed sensor.
      Fig 2: Locating Bolt And Rear Speed Sensor

      Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      NOTE:

      Prevent foreign matter from attaching to the sensor tip.
