Initializing Tire Pressure Monitor System
NOTE:
Perform initialization AFTER the transmitter ID registration procedure (if registration is required).
NOTE:
Perform initialization in the following cases:
- After replacement of the tire pressure warning ECU.
- After replacement of a tire pressure sensor.
- Specified tire pressure changes.
- Changing the standard tire inflation pressure value due to trailer towing.
NOTE:
Initialization is NOT required if re-inflating tires to the specified tire pressure.
- Set the tire pressure of all wheels to pressure specified on the tire and loading information label.
- With the vehicle stopped and parking brake applied, turn the engine switch ON (IG).
- Use the LEFT/RIGHT Arrow buttons on the right-hand steering wheel control pad (see Fig 1) and select the GEAR icon.
- Use the UP/DOWN Arrow buttons and select "Vehicle Settings". Then press ENTER (center button).
- Use the UP/DOWN Arrow buttons and select "TPMS". Then press and hold ENTER until a message is displayed.
- The message will be displayed on the multi-information display and the tire pressure warning light will blink slowly 3 times. When the message disappears, initialization is complete.
