Removal [09/2015 - ]: Procedure

REMOVE COWL TOP VENTILATOR LOUVER RH
Refer to PROCEDURE - Step 2
PRECAUTION
NOTE:
After turning the engine switch off, waiting time may be required before disconnecting the cable from the battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal notice before proceeding with work (Refer to PRECAUTION [09/2015 - ] ).
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
NOTE:
When disconnecting the cable, some systems need to be initialized after the cable is reconnected (Refer to INITIALIZATION [09/2015 - ] ).
REMOVE CONSOLE BOX ASSEMBLY
1. w/ rear seat entertainment system:
  (Refer to REMOVAL [09/2015 - ] )
2. w/o rear seat entertainment system:
  (Refer to REMOVAL [09/2015 - ] )

REMOVE NO. 1 CONSOLE BOX DUCT

Detach the connector clamp (labeled A).

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

REMOVE YAW RATE SENSOR

Remove the 2 bolts and sensor.

TEXT IN ILLUSTRATION

*a	Identification Number

Disconnect the sensor connector.
NOTE:
- Make sure the yaw rate sensor's identification number is 9.
- Do not drop the yaw rate sensor. If it is dropped, do not use it.
