Components [01/2017 - ]
| *1 | LOWER RADIATOR AIR DEFLECTOR | *2 | RADIATOR SUPPORT TO FRAME SEAL RH |
| *3 | V-BANK COVER SUB-ASSEMBLY | - | - |
Fig 2: Camshaft Oil Control Valve (For Bank 2) Replacement Components With Torque Specifications (2 Of 2)
| *1 | CAMSHAFT TIMING GEAR BOLT (for Intake Side of Bank 2) | *2 | CAMSHAFT TIMING GEAR BOLT (for Exhaust Side of Bank 2) |
| *3 | CAMSHAFT TIMING OIL CONTROL SOLENOID ASSEMBLY (for Intake Side of Bank 2) | *4 | CAMSHAFT TIMING OIL CONTROL SOLENOID ASSEMBLY (for Exhaust Side of Bank 2) |
| *5 | WIRING HARNESS CLAMP BRACKET | *6 | ENGINE WIRE |
| *7 | O-RING | - | - |
| N.m (kgf/cm, ft.lbf): Specified torque | • | Non-reusable part | |
| Adhesive 1324 | * | Precoated part |
