Components [09/2015 - ]

Fig 1: Mass Air Flow Meter Replacement Components
GTY654226Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 AIR CLEANER CAP WITH AIR CLEANER HOSE *2 MASS AIR FLOW METER SUB-ASSEMBLY
*3 NO. 1 FUEL VAPOR FEED HOSE *4 NO. 2 VENTILATION HOSE
