Removal/ Installation

Distributor R&R:

1. Remove in order shown.
2. Install in reverse order.
3. Adjust timing.
4. Tighten hold-down bolt to 14 - 18 ft lb (19 - 25 Nm).

COMPONENTS

1. Battery cable.
2. Fresh air duct.
3. Air cleaner housing.
4. High-tension lead.
5. Connector.
6. Distributor.
