Removal and Installation of Rear Audio Remote Control Unit

WARNING: This page is about a different car, the 2004 Nissan Titan. However, it is still accessible from the selected car via links, so may be relevant.

Carefully remove the rear audio remote control unit from the roof console assembly.
CAUTION: Wrap removal tool with clean shop cloth to prevent damage to the headliner.
Disconnect connector and remove the rear audio control unit.
Installation is in the reverse order of removal.

Fig 1: Identifying Rear Audio Remote Control Unit
Courtesy of NISSAN MOTOR CO., U.S.A.
