DTC Confirmation Procedure

NOTE: If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

WITH CONSULT-II

Turn ignition switch to ON position. (Do not start engine.)

Fig 1: DTC Confirmation Procedure With CONSULT -II
Courtesy of NISSAN MOTOR CO., U.S.A.
Select DATA MONITOR mode for ENGINE with CONSULT-II.
Start engine and wait for at least 6 seconds.
If DTC is detected, go to DIAGNOSTIC PROCEDURE .

WITH GST

Follow the procedure WITH CONSULT-II.
