Dynamic Damper

  1. Use a new damper band when reinstalling.
  2. Install dynamic damper from stationary-joint side while holding it securely:
    Fig 1: Identifying Dynamic Damper Dimensions
    G01318958Courtesy of NISSAN MOTOR CO., U.S.A.
    Fig 2: Dynamic Damper Dimension Chart
    G01318959Courtesy of NISSAN MOTOR CO., U.S.A.
