Crankshaft Position Sensor (OBD)
Fig 1: Crankshaft Position Sensor (OBD) Voltage Specification Chart
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
