Dynamic Damper

WARNING: This page is about a different car, the 2004 Nissan Altima, 2003 Nissan Altima, and 2002 Nissan Altima. However, it is still accessible from the selected car via links, so may be relevant.
  1. Use new damper bands when installing.
  2. Install dynamic damper from stationary-joint side while holding it securely.
    Fig 1: Identifying Damper Bands Length
    G02887317Courtesy of NISSAN MOTOR CO., U.S.A.
    Fig 2: Engine Applied Model Chart
    G02887318Courtesy of NISSAN MOTOR CO., U.S.A.
