Check For MAIN Switch

WARNING: This page is about a different car, the 2005 Infiniti FX45 and 2005 Infiniti FX35. However, it is still accessible from the selected car via links, so may be relevant.
  1. Start the engine. Then, check the following operations are carried correctly.
  2. "CRUISE" lamp illuminates and ICC system indicator goes off when MAIN switch is pressed "ON" for more than 1.5 seconds, and then ready for operation. The illumination goes off when MAIN switch is turned to OFF.
  3. "CRUISE" illumination go off when the key switch is turned to OFF while MAIN switch is ON.
    Fig 1: Identifying MAIN Switch Screen
    G02359914Courtesy of NISSAN MOTOR CO., U.S.A.
