All Warning Chimes Do Not Operate

WARNING: This page is about a different car, the 2005 Nissan Xterra. However, it is still accessible from the selected car via links, so may be relevant.
  1. CHECK BCM CHIME OPERATION

    Select "BUZZER" on CONSULT-II, and perform "LIGHT WARN ALM""IGN KEY WARN ALM", or "SEAT BELT WARN TEST" active test.

    Does chime sound?

    1. YES : Replace the BCM. Refer to "REMOVAL AND INSTALLATION OF BCM ".
    2. NO : Replace the combination meter. Refer to "COMBINATION METER ".
      Fig 1: CONSULT-II Display - BUZZER
      G03610217Courtesy of NISSAN MOTOR CO., U.S.A.
